Technical parameters

Voltage: AC200V ~ 50 ~ 60 hz, 240 v

Power: 2500 w bulb: XQ2KW

Lamp life: 1000 hours (600 hours after light bulb started to droop)

Protection grade: IP44

Special design reflective bowl, produce high brightness output

X: 540 °, photosensitive error correction function, can automatic correction place of lamps and lanterns.

X axis fine-tuning: 5.4 ° fine-tuning, more accurate positioning.

Y fine-tuning: 270 °, with photosensitive error correction function, can automatic correction place of lamps and lanterns.

Y axis micro controller: 5.4 ° fine-tuning, more accurate positioning, white + CMY color change systems,

Multiple colors can be combined from. Parallel light output, and the projection distance of 2 km,

Beam size 250 mm in diameter

Body of overvoltage and overheating, overload, short circuit protection.

Dimension: 500 * 420 * 730 mm

Packing size: 570 * 470 * 840 mm

Control signals: DMX - 512 program within a single function since go,

Program in many sets of master-slave synchronization control signal reset function, X Y reverse.
