Input voltage/frequency: AC100V-240V, 50/60Hz.
Rated power: 430W/470W/500W/560W.
Light source: use 330W/350W/380W/440W osram or philips bulbs
Light angle: 3.8°-35° adjustable
Control channel: 20/16 international standard DMX512 channels.
Operation mode: sound control, auto movement, master-slave, DMX512.
Color wheel: 11 colors + blank, linear color conversion and rainbow effect.
Fixed gobo: 17 gobos + blank.
Rotary gobo: 9 glass gobos + blank
Prism: 1 prism, can choose 8, 16, 24, 48 facet prisms, prism forward and reverse free rotation function
Focus: DMX linear high-definition focus, spot zoom in and out,2 meters to infinite definition adjustment, and the definition of the gobo can be adjusted freely.
Frost: built-in frost effect adjustment.
Strobe: Double-chip high-speed strobe, 1-15 times per second ,ultra-high-speed strobe effect.
Dimmer: 0-100% mechanical linear dimmer.
Horizontal/Vertical: Horizontal scanning angle is 540°, vertical scanning angle is 270°, 8 or 16 bit fine resolution, automatic return correction function;
Fast speed, smooth operation, no flick, low noise, accurate positioning.
Display interface: LCD, can switch between Chinese and English.
Lamp housing: high temperature resistant engineering plastics and alloy materials, streamlined design, beautiful and generous appearance.
Protection level: IP65.
The console can be used to light the lamp, and the bulb can be switched on and off with delay function.
Dimensions: L393×W430×H680mm
Package size: L490×W410×H765mm
N.W: 25KGS, G.W: 30KG
